Pacific Automotive Industries

Complete Set: Ford Transit 2000 Front Wheel bearing tool set + 32 ton Ram + Foot Pump

Order Set #10003


Foot pump #1036

  • Premium Air over hydraulic foot pump has variable speeds for fine control.
  • Top Quality Hydraulic Pump built entirely of Aluminum and Brass for long life.
  • Mechanicals are all produced on a C&C machine for uniformity.
  • Maximum pressure is 10,000 PSI. It is used with all of our hydraulic cylinders.
  • Foot pump comes with a pressure gauge.
  • Premium 7 ft. hose and drip-free quick disconnect female coupling.
  • Oil tank holds 1/3 gallon (1.3 Liters)

32 Ton Ram #03-00028

  • 32 tons pressing and pulling hydraulic cylinder can be used every day in auto repair shops.
  • Primarily a 32 ton cylinder is for our wheel bearing tools for light commercial vehicles and trucks.
  • It is universal and can be used with carriage beams M10-M22 with the proper adaptor.
  • The cylinder's hydraulic pressure can be combined with hammer blows when using a punching socket
  • Weight: 18 lbs (8.2 kg). Stroke: 4.4” (112 mm).

Parts in the set:
03-00028-001 – Hydraulic cylinder 32 tons
RES 1090-05-02 – Adjustable press rod 4.3” (109mm), M24
RES 1090-05-04 – Thread protection ring (2.5″)
RES4025 – Flange nut M22
RES4027 – Carriage beam M22, 10” (250mm)
1091-17-M22 – Punching nut M22
1086-6 – Punching socket M22
RES4306 – Hydraulic quick coupling, male

32 Ton Ram video
